The DTU-315 is a pocket-size modulator for USB-3 with support for all popular satellite, terrestrial and cable standards currently in use around the world.
The output is fully agile from 36MHz to 2150MHz, covering the entire VHF, UHF and L-band. All-digital modulation technology is used to create excellent signal quality at the RF output.
The modulation bandwidth extends from 100kHz to 70MHz, making the DTU-315 the perfect modulator for standards ranging from DVB-T2 lite to the most advanced satellite standard DVB-S2X.
A single cable supplies power, data and control to the DTU-315. No external power supply is required, making day-to-day operation very convenient.
For developers this is the ideal modulator in the lab for developing or qualifying any equipment with an antenna input. For traveling sales men, the unit is easy to carry to trade shows and demos.
The DTU-315 is also an easy-to-install fit in fixed set ups, e.g. for production testing in a manufacturing line. A rackmount kit is available for easy mounting in a 19-inch rack.
